Polygonal Box with Lid

Number of Sides Inner Diameter Clearance Height

Tube-shaped (prismatic) box-with-lid with a regular polygon as a base. This template can be used to create a triangular box, a square box or a box in the shape of a pentagon, hexagon,… etcetera.

This design consists of a base tray and a lid. The Inner Diameter and the Number of Sides determine the dimensions of the base tray. By default, the cover is 5% larger then the tray but this can be adjusted using the Clearance. For ease of use, Clearance is set as a percentage.
